Product specification
Exterior Material
Powder coated deep-drawn steel panels
Exterior Finishes
Multiple colour options available
Exterior Glass
Sound control laminated glass
Exterior Frame
Semi-gloss black frames made from steel & aluminium
Door
Left or right handed - Doorway 2040 mm. Clear opening width 1015 mm
Interior Walls / Roof
A sandwich element chassis, made of deep-drawn sheet metal & recycled acoustic foam. Fabric interior panels and an anti-static and stain resistant low loop pile carpet for the floor.
Interior Electric Height Adjustable Table
Formica laminate on birch plywood with varnish trim. The table can be placed vertically between 700 mm - 1200 mm to allow for different working positions and provide comfort to all users
Interior Table Dimensions W x D x H (mm)
760 mm x 450 mm x 700mm-1200mm
Power
One power Socket + USB C Socket
Power Consumption
35 W while in use - LED light: 19 W, Fans in total: 7 W. 6 W standby power consumption - Fans are working on 25 % of the maximum power. Maximum power consumption - 80 W total
Lighting
LED Light
UI Panel
High Resolution Touchscreen
Exterior Width
1220 mm
Exterior Depth
1000 mm
Exterior Height
2255 mm
Interior Width
1020 mm
Interior Depth
930 mm
Interior Height
2040 mm
Weight
325kg
Airflow
Maximum airflow is 29 l/s (Minimum recommended space for the air to circulate is 5cm / 1,9" on the sides - 20cm / 8" above the pod)
Acoustics
Speech level reduction according to ISO 23351-1 testing method >30dB
Optional Outlets
Wireless Charger / LAN
Framery Overview
Framery One is not only stylish and super smart, it incorporates the latest technology, leading sound insulation standards and echo-free acoustics. This video gives you a brief overview of the Framery One Meeting Pod
